Description
Fans: 1 fan tray slot (Includes: 1 x J9832A)
IPv6 functionality: IPv6 host: Enables switches to be managed in an IPv6 network; Dual stack (IPv4 and IPv6); IPv6 ACL/QoS: supports ACL and QoS for IPv6 network traffic; IPv6 routing: supports static and OSPFv3 routing protocols
L2 network standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1ad, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.3ad , IEEE 802.3x, IEEE 802.1ab, IEEE 802.1X, IEEE 802.1AE, IEEE 802.3az L3 network standards: Static IP routing: provides manually configured routing for both IPv4 and IPv6 networks, Routing Information Protocol (RIP): provides RIPv1 and RIPv2 routing, OSPF: provides OSPFv2 for IPv4 routing and OSPFv3 for IPv6 routing
MAC addresses: 64000 MAC address table size
Power Over Ethernet (PoE): No
QoS: Advanced classifier-based QoS, Traffic prioritization, Bandwidth shaping, Class of service (CoS): sets the IEEE 802.1p priority tag based on IP address, IP Type of Service (ToS), Layer 3 protocol, TCP/UDP port number , source port, and DiffServ
Routing: Layer 3 Advanced
Stackable: Yes
Uplink ports: 0
VLAN (number, standards): VLAN support and tagging: supports the IEEE 802.1Q standard and 2,048 VLANs simultaneously; IEEE 802.1v protocol VLANs: isolate select non-IPv4 protocols automatically into their own VLANs
Warranty: 99 months
Power supply: 4 power supply slots - 2 minimum power supply required (ordered separately) Routing/switching capacity, Gbps: 1920 Gbps
Total number of ports: 0
Mounting option: Rackmount, 7U Rack
Primary ports, type: 0
Memory (Flash, RAM): Flash Memory: 16 MB, RAM: 4 GB DDR3 SODIMM
Bandwidth, Mpps: 1142.8 Mpps
Dimensions (W, L, H), mm: 445 x 451 x 307
Free (10GB) slots: 12 open module slot; Supports a maximum of 288 autosensing 10/100/1000 ports or 288 SFP ports or 96 SFP+ ports or 96 HP Smart Rate Multi-Gigabit or 24 40GbE ports, or a combination
Security: Switch CPU protection: provides automatic protection against malicious network traffic trying to shut down the switch; Virus throttling: detects traffic patterns typical of WORM-type viruses
Switch, type: Modular Management: IMC—Intelligent Management Center; Command-line interface; Web browser; Configuration menu; Out-of-band management (RJ-45 Ethernet); SNMP Manager; Out-of-band management (serial rs-232c or micro usb)
