Description
Fans: 3 x Smart fansIPv6 функционалност: IPv6 Traffic Class, IPv6 Flow Label, IPv6 Snooping, IPv6 Route Advertisement (RA) Guard, IPv6 ND Inspection, IPv6 ND Entries:1024L2 мрежови стандарти: IEEE 802.3, IEEE 802.3u, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1X, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1v, IEEE 802.1AX/802.3adL3 мрежови стандарти: IPv4/IPv6 Static Route; IPv4/IPv6 Default Route; RIPv1/v2/ng; OSPF: OSPF v2/v3, OSPF passive interface, Stub/NSSA area, Support Equal-Cost Multi-Path Route (ECMP), Text/MD5MAC адреси: 16000 MAC address table sizePower Over Ethernet (PoE): NoQoS: 802.1p; 8 queues per port; Queue Handling - Strict Priority, Weighted Round Robin (WRR), Strict + WRR, Weighted Deficit Round Robin (WDRR); Policy Map; Congestion Control - Weighted Random Early Detection (WRED); Bandwidth Control; Three Color MarkerRouting: Layer 3 AdvancedStackable: 4 Stacking ports; When stacking the DGS-3130-30TS/30S/30PS models, the stacking cost is 1 per unit so the maximum units per stack is 9.Uplink портове: 4x10GE SFP, 2x10GBase-TVLAN (брой, стандарти): 802.1Q; Auto Surveillance VLAN; Port-based VLAN; 802.1v Protocol-based VLAN; Voice VLAN; MAC-based VLAN; VLAN translation; VLAN Group - Max. 4K VLAN groups, Max. 1~4094 VIDs; GVRP - Max. 4K dynamic VLAN groups; Double VLAN (Q-in-Q) - Port-based/SelectiveГаранция: 99 месецаДруги: 1 x RJ-45 Console port, 1 x RJ-45 Management port, 1x USB 2.0 Type A portЗахранване: Power Input: 100 to 240 VAC, 50 to 60 Hz; Optional Redundant Power Supply (DPS-500A)Капацитет за маршрутизиране/превключване, Gbps: 168 GbpsОбщ брой портове: 30Опция за монтаж: RackmountОсновни портове, тип: 24xSFPПамет (Flash, RAM): Packet Buffer Memory: 2 MBПропускателна способност, Mpps: 125 MppsРазмери (Ш, Д, В), mm: 440 x 250 x 44 mmСвободни (10GB) слотове: NoСигурност: Port Security - supports up to 64 MAC addresses per port; Broadcast/Multicast/Unicast Storm Control; D-Link Safeguard Engine; DHCP Server Screening; IP Source Guard; DHCP Snooping; Dynamic ARP Inspection (DAI); DHCPv6 Guard; SSL; SSHСуич, тип: Fixed PortУправление: Web-based GUI; Command Line Interface (CLI); Telnet Server/Client for IPv4/IPv6; SNMP (Support v1/v2c/v3, Support for IPv4/IPv6 access); SNMP Traps; sFlow; RMON v1/v2; LLDP/LLDP-MED; BootP/DHCP Client; D-Link Discover Protocol (DDP); SMTP; NTPv3/v4
